APL-210N Pneumatic valve limit switch box with bracket CE certificate
►Features
| SPECIFICATION | STANDARD | OPTION | MATERIAL |
| Enclosure | Weatheproof IP67/NEMA4 & 4X | IP68 | Housing cover&body | Aluminium die-casting |
| Shaft | Stainless steel |
| Ambient temperature | -20ºC~80ºC | | Indicator cover | Polycarbonate |
| Indicator | ABS/Polycarbonate |
| Cable entries | 2 x NPT1/2" | PF1/2",PT1/2"
M20,PG13.5 | Cam | Polycarbonate |
| Spring | Stianless steel |
| Position indicator | Closed:red Open:yellow | Closed:red Open:green | Housing cover bolt | Stianless steel |
| Switches | Mechanical switch x 2
Proximity sensor x 2 | | O-ring | NBR |
| Bushing | Bronze |
| External coating | Polyester powder coating(black) | red,green,blue,
yellow,siliver color,
Nylon coated | E-ring(shaft) | Stianless steel |
| Earth lug | Stianless steel |
| Shaft | Standard shaft(17mm) | Long shaft | Bracket | Stianless steel |
►Standard Parts Technical Data
| Features: | | | | | |
| 1.Solid and Beautiful Design Aluminum die-casting housing and powder coated. | |
| 2.Bolts on Visual Position Indicator Secure weatherproof. | |
| 3.Quick-Set Cam spring loaded splined cam No need to adjust again after initial setting Easy setting without tool. | |
| 4.Multi point terminal strip Standard 8 point and enough strips for connection. | |
| 5.Dual cable entries.2*1/2NPT 2*3/4PF. | |
| 6.Easy Mounting NAMUR standard stainless steel shaft and bracket. | |
| Technical Data | | | | | |
| Model | APL-2N | APL-3N | APL-4N |
| Standard | Option | Standard | Option | Standard | Option |
| Enclosure Explosion Proof | IP67 | IP67 | IP67 Eexd B T6 (EN50014/50018) |
| Temperature Range | 2585 |
| Cable Entry | 2×1/2NPT | PT1/2 PF1/2 M20,PG13.5 | 2×1/2NPT | PT1/2 PF1/2 M20,PG13.5 | 2×3/4NPT | PT3/4 PF3/4 M20,PG13.5 |
| Terminal Strips | 8 | | 8 | 924 | 8 | 924 |
| Position Indicator | 090° | 0180° | 090° | 0180° | 090° | 0180° |
| Open-Yellow;Close-Red |
| Swiches | Mechanical Swither,Proximity Sensor |
►Options Parts Technical Data
►APL limit switch
►Package
1. Packing Details : Carton, Pallet and Wooden package depends on weight and customer request ;
2. Payment Iteam :Western Union ; T/T of 100% before delivery.
3. Shipping Details : We prefer to use your forwarder if you have agent in China OR we will use our forwarder,usually we use,DHL/UPS/Fedex,and the shipment cost basic on weight,we would caculate it show in PI once order confirm.
4. Delivery Details : 6-8 weeks after confirmation of PO and down payment .
